Features & Benefits
Set works:
- Cleereman Controls Resaw Setworks
- 15 preset locations
Frame:
- Heavy duty tubular steel construction
Feed System:
- Multiple inlayed bed chain
Band Saw Specifications (Saws not Included):
- 10” wide, 36’ long band for 62″ wheel (8″ wide, 32′ long band for 54″ wheel)
- Air strain band tension
- BioLube band oiler (Included)
- 2″ Tooth Spacing
Guides:
- Interchangeable pressure guides
- Guide dresser included
Drive Wheels:
- 54″ or 62” diameter high quality ductile steel wheel
- Wheel scraper cleaner
- 4140 Alloy Shafts
Hold downs:
- Powered press-roll hold downs
- Front and rear locations
Cutting Cap:
- 20” wide x 20 high on 62″ (18″ wide x 18″ on 54″)
Motors:
- 150 H.P. TEFC drive motor on 62″ (125 H.P. on 54″)
- 5 H.P. variable speed feed drive
Electrical MCP:
- Includes all TEFC motors, starters, breakers.
- 440-volt standard
- System comes completely tested at factory
- Customer responsible for main electrical drop to MCP panel and to wire from MCP to motors
Dust Removal:
- 8″ diameter outlet
- Dust suction system with 5000 CF of air flow recommended (Not Included)
Resaw Infeed
- 16’ Infeed
- Chain style cant turners
Resaw Outfeed
- Inertia style horizontal style outfeed
- Skate roll waste tipples
- Skate roll board tipple
Cleereman Controls for the Resaw Runaround
- Pre-mounted in Resaw cab
